Yokogawa bears no liability for any problems that may occur during download or installation of this software.

WAVEFORM VIEWER SOFTWARE SOFTWARE

The contents of this software are subject to change without prior notice as a result of continuing improvements to the software's performance and functions.Also, Yokogawa may not be able to accept inquiries regarding repair of defects in or questions about this software.This software is offered free of charge, but no unlimited warranties are made against any defects whatsoever.Under no circumstances is any dumping, reverse compiling, reverse assembly, reverse engineering, or any other kind of alteration or revision of this software allowed.The property rights, proprietary rights, intellectual property rights, and all other rights associated with the software are held by Yokogawa Test & Measurement Corporation.Data saving (save the display waveform in CSV or WVF format.).Arbitrarily set the upper and lower limits of the waveform display.Scrolling function for the zoomed waveform.

Main waveform display, zoom waveform display, history waveform display, X-Y waveform display.

The following (limited) functions are only available for this free software.

In both cases, files must contain 100 or more data points.

Data that has been recorded in realtime using the DL708E/DL716 (.rtm data.).

WAVEFORM VIEWER SOFTWARE SERIES

Data measured by the Yokogawa DL series ¹, or WE7000 that have been saved in binary format.

Microsoft Windows NT 4.0 or later, Windows 95/98, Windows 2000, Windows Me, or Windows XP.

WAVEFORM VIEWER SOFTWARE PC

PC on which Windows 95/98, Windows NT 4.0 or later, Windows 2000, Windows Me, or Windows XP runs.ģ2 MB or more (64 MB or more recommended) Waveform files can be converted to ASCII format (CSV format). You can also stack multiple displayed waveforms, and select which waveforms to stack. History mode allows you to display a list of multiple waveforms captured in history memory. It is also easy to zoom along the vertical axis of a waveform using the mouse, and the zoom box can be moved (scrolled) automatically and continuously. The display can be zoomed to a specified enlargement mgnification.
